Customized special-shaped tube die

We specialize in engineering and manufacturing high-precision custom special-shaped tube dies and roller tooling tailored to your exact drawings, material specifications, and mill parameters. Backed by rich practical experience in the tube forming industry, we provide reliable tooling solutions for complex custom geometries—including oval, rectangular, triangular, multi-grooved, embossed, plum blossom, and non-standard geometric tubing.

Key Features & Technical Advantages

• Premium Tool Steel & Heat Treatment: Precision-machined from high-grade alloy mold steel (such as Cr12MoV, D2, or SKD11) and treated with advanced heat treatment to achieve high surface hardness, maximum wear resistance, and long service life during continuous heavy-duty steel tube rolling.

• High Precision & Smooth Surface Finish: Machined with CNC equipment and fine surface polishing to minimize friction, prevent material dragging, and maintain high dimensional consistency.

• Fully Adjustable Modular Set: All dimensions of the complete die set can be customized and adjusted to match your exact production wall thickness, tube profile limits, and mill setup.

• Excellent Forming Stability: Optimized roll pass design reduces internal material stress, prevents profile twisting, and guarantees tight seam alignment for high-speed continuous tube manufacturing.

• Versatile Custom Profile Capabilities: Proven track record in developing tooling for intricate non-standard profiles, decorative architectural tubing, structural frames, and custom industrial pipes.

Applicable Materials & Profiles

• Workpiece Materials: Stainless steel (200 / 300 / 400 series), carbon steel, alloy steel, titanium, copper, and aluminum tubing.

• Tube Profiles: Rectangular, square, oval, D-shape, plum blossom, concave/convex grooved, embossed pattern, triangular, trapezoidal, and fully customized OEM geometries.

• Target Applications: Architectural hardware, furniture frameworks, automotive structural piping, decorative railings, heat exchangers, and industrial machinery frames.

Customization & OEM Process

1. Technical Drawing Review: Send us your detailed CAD/STEP/PDF drawings or physical tube samples.

2. Pass Design & Material Selection: Our engineering team recommends the optimal tool steel grade and roll pass design according to your material yield strength and machine dimensions.

3. CNC Precision Manufacturing: Precision turning, milling, vacuum heat treatment, EDM wire cutting, and surface finishing.

4. Quality Inspection: Comprehensive dimensional calibration, hardness testing, and profile accuracy checks prior to packaging.

Why Partner With Us?

With extensive R&D and manufacturing experience in custom roll forming dies, breakdown rollers, and sizing pass tooling, we deliver end-to-end solutions for tube manufacturers worldwide. We support full OEM & ODM customization—whether you have complete engineering drawings or just product ideas, our technical team provides tailored solutions and reliable technical support from design evaluation to final setup.

Contact Us Today

Upgrade your tube mill productivity with custom-engineered roller tooling. Submit your technical drawings or project parameters today to receive a factory-direct quote and design evaluation!
